method: iAtkos s3 ver2 10.6.3
( this method also works for Toshiba Satellite M100 PSMADA 01E00D, BIOS version 5, and probably with other m100 models )
Files needed:
iAtkos s3 ver2 10.6.3 iso image (search torents) – and burn on DVD
Toshiba M100-165 Extra Files can be found here or here (copy to usb or cd)
Installation of OS X 10.6.3 Snow Leopard on Toshiba Satellite M100-165 PSMA1E May 24, 2011 Tutorials 10.6.3, 32 bit, ALC861, ati, ati mobility radeon x1400, hackintosh, intel core duo T2300, intel pro/100 vm, intel pro/wireless 3945ABG, Mobile Intel Calistoga i945PM, os x install, Snow Leopard, toshiba, Toshiba Satellite M100-165. Buy TOSHIBA Laptop Satellite L305-S5962 Intel Pentium dual-core T4200 (2.00 GHz) 2 GB Memory 250 GB HDD Intel GMA 4500M 15.4' Windows Vista Home Premium with fast shipping and top-rated customer service. Newegg shopping upgraded ™.
Toshiba m100-165 PSMA1E hardware specifications:
MOBO: Mobile Intel Calistoga i945PM.
MOBO integrated Graphics adapter: Ati mobility radeon x1400 256mb (PCI ven 1002 dev 7145 ( QE/CI enabled, 1280×800)).
MOBO integrated Lan:Intel pro/100 vm (pci ven 8086 dev 1093).
MOBO integrated Audio: Realtek high definition audio ALC861 (ven 10EC dev 0861).
MOBO integrated Wireless: Intel pro/wireless 3945ABG (pci ven 8086 dev 4222) (not working).
CPU:Intel core duo T2300 1.66 GHz 2MB L2 Cache, FSB 677MHz.
RAM: 3g pc6400 2+1 DDR 2 800MHz memory (usually this laptop comes with only 512Mb of RAM(pc4200), u should upgrade this for snowleo, mobo supports up to 4GB…).
This tutorial is for educational purposes only. You, of course, assume all responsibility for choosing to follow this tutorial. Also, OS X EULA states that you can run Snow Leopard on Apple labeled hardware only.
INSTALLATION:
Bios Settings (V3.00):
Turn on your comp, press F2 to load BIOS, and set it up like on photos below …
Press F10 to save changes, and exit.
At boot press F12 to select your boot device, Insert your iAtkos s3 DVD in your DVD rom and select DVD Rom as boot device.
Now wait for installation screen, choose your language, agree to the terms, and select disk utility under utilities in upper menu. Format your hard drive like GUID Partition Table (your data will be lost).
( Click here to found out how to install OS X, and how to partition your HDD Drive )
Close Disk utility, and when installation screen appear, select your HDD and press Customize. Than check next options:
Proceed with install, and wait until installation complete.
After Install Succeeded, reboot, and wait for system to boot. This may take a while at first boot.
System should start now, enter your keyboard layout, location and registration and you are ready for the next step.
Unzip Toshiba_M100-165_Extra_Files.zip u downloaded earlier, copy radeonHD.kext, ATIRadeonX1000.kext and IONetworkingFamily.kext to System/Library/Extensions.
Run Kext Utility application from extra pack, to clear kext catche and rapair permisions. ignore errors if any.
Run Terminal from Utilities and enter “sudo pmset -a hibernatemode 0” without quotes, press enter, type your password and hit enter again.
Run DSDT patcher from Toshiba_M100-165_Extra_Files, and when file dsdt.aml is created, copy it to your hdd root. (u can also try to use existing dsdt.aml from Extra_Files instead of patching new one)
Toshiba Mac Driver
Now reboot, and cross your fingers 🙂
System should start now with 1280×800 resolution with QE/CI enabled. Go to System Preferences and select Network. Your new network should appear now, hit apply and your network is up and running.
In System Preferences choose Energy Saver and disable it cause sleep will cause u trouble…
Im still not able to run wireless card, but its easy fix with numerous OSX compatible USB wireless cards u can buy cheap…
I haven’t tested voodoo battery drivers because my battery is dead, but i think it should work as well .
Toshiba Satellite Laptop Manual
Update to 10.6.6 combo ( http://support.apple.com/downloads/DL1349/en_US/MacOSXUpdCombo10.6.6.dmg ) causes problems with cursor, so after update, again, copy radeonHD.kext and ATIRadeonX1000.kext to System/Library/Extensions.
Run Kext Utility, restart.
Enjoy your new HACKIN-TOSHIBA 🙂
Mac Os For Toshiba Satellite Drivers
Known bugs:
– intel pro/wireless 3945ABG drivers not working (anyway u should check development of drivers at http://code.google.com/p/iwidarwin/ and wait until somebody makes it work ). Alternative is to buy USB wireless or another mini pci wireless card to replace your intel pro/wireless 3945ABG.
– intel pro/100 vm every now and than fails to connect to network (just reboot and it works, it happens to me in one of 20 boots).
– sleep wont work (u should disable sleep in System Preferences / Energy Saver)
– system halts on start every now and than (i think its graphic card kexts) but just restart and everything should work ok again.
